Stauff SP-020-E-10-B/4 Replaces the Stauff SP020E10B4
Stauff SP-020-E-10-B/4 Pressure Filter
SP-020-E-10-B/4
Stauff
Stauff
Brand:
Stauff
Description
Replacement Filter Element for Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 45,5 Inner Diameter (mm): 25,6 Length (mm): 207 Sealing: NBR, β ratio >200
Regular price
$103.00
Unit price
per
Germany
8421.99.90
0.66 kg
0.0004 m³
United Kingdom
8421.99.90
0.3 kg
0.0005 m³
France
8421.99.90
0.14 kg
0.0004 m³
Italy
8421.99.90
Description
Replacement Filter Element for Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 45,5 Inner Diameter (mm): 25,6 Length (mm): 207 Sealing: NBR, β ratio >200Specification
| Style | Pressure Filter |
| Media | Glass Fiber |
| Efficiency 1 | 10µ @ β200 |
| Efficiency 2 | 12µ @ β1000 |
| Outer Diameter | 45.0 mm |
| Inner Diameter | 25.5 mm |
| Length | 209.0 mm |
| Δ Collapse Pressure | 21 bar |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
