Stauff SP-020-E-03-B/4 Replaces the Stauff SP020E03B
Stauff SP-020-E-03-B/4 Pressure Filter | Replaces the Stauff SP020E03B
SP-020-E-03-B/4
Stauff
Stauff SP020E03B
Stauff
Stauff SP020E03B
Brand:
Stauff
Description
Replacement Filter Element for Pressure Filters Micron Rating: 3 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 45,5 Inner Diameter (mm): 25,6 Length (mm): 207 Sealing: NBR, β ratio >200
Regular price
$111.00
Unit price
per
1596 pcs
Germany
8421.99.90
0.66 kg
0.0004 m³
1596 pcs
United Kingdom
8421.99.90
0.31 kg
0.0004 m³
1596 pcs
Italy
8421.99.90
0.28 kg
0.0008 m³
1596 pcs
France
8421.99.90
0.23 kg
0.0009 m³
1596 pcs
United States
8421.29.80.90
0.23 kg
0.0009 m³
1596 pcs
Mexico
8421.23.00
Description
Replacement Filter Element for Pressure Filters Micron Rating: 3 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 45,5 Inner Diameter (mm): 25,6 Length (mm): 207 Sealing: NBR, β ratio >200Specification
| Style | Pressure Filter |
| Media | Glass Fiber |
| Efficiency 1 | 3µ @ β200 |
| Efficiency 2 | 5µ @ β1000 |
| Outer Diameter | 45.0 mm |
| Inner Diameter | 25.5 mm |
| Length | 209.0 mm |
| Δ Collapse Pressure | 21 bar |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
Stauff Product
Genuine Stauff SP-020-E-03-B/4
Inspected to ISO 9001:2015
