Stauff SP-010-E-05-B/4 Replaces the Stauff SP010005E
Stauff SP-010-E-05-B/4 Pressure Filter | Replaces the Stauff SP010005E
SP-010-E-05-B/4
Stauff
Stauff SP010005E
Stauff
Stauff SP010005E
Brand:
Stauff
Description
Replacement Filter Element for Pressure Filters Micron Rating: 5 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 45,5 Inner Diameter (mm): 25,6 Length (mm): 112,5 Sealing: NBR, β ratio >200
Regular price
$142.00
Unit price
per
1560 pcs
Germany
8421.99.90
0.35 kg
0.0002 m³
1560 pcs
United Kingdom
8421.99.90
0.13 kg
0.0005 m³
1560 pcs
France
8421.99.90
0.18 kg
0.0007 m³
1560 pcs
Italy
8421.29.80.90
0.08 kg
0.0002 m³
1560 pcs
Italy
8421.99.90
Description
Replacement Filter Element for Pressure Filters Micron Rating: 5 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 45,5 Inner Diameter (mm): 25,6 Length (mm): 112,5 Sealing: NBR, β ratio >200Specification
| Style | Pressure Filter |
| Media | Glass Fiber |
| Efficiency 1 | 5µ @ β200 |
| Efficiency 2 | 7µ @ β1000 |
| Outer Diameter | 45.0 mm |
| Inner Diameter | 25.5 mm |
| Length | 113.0 mm |
| Δ Collapse Pressure | 21 bar |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
