Stauff RE-160-G-10-B/4 Replaces the Stauff RE160E10B
Stauff RE-160-G-10-B/4 Return Filter | Replaces the Stauff RE160E10B
RE-160-G-10-B/4
Stauff
Stauff RE160E10B
Stauff
Stauff RE160E10B
Brand:
Stauff
Description
Replacement Filter Element for Return-Line Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 114 Inner Diameter (mm): 68,2 Length (mm): 334 Sealing: NBR, β ratio >200
Regular price
$334.00
Unit price
per
72 pcs
Germany
8421.99.90
1.72 kg
0.0066 m³
72 pcs
France
8421.99.90
1.08 kg
0.0057 m³
72 pcs
United States
8421.29.80.90
2.1 kg
0.0043 m³
72 pcs
Italy
8421.99.90
2.1 kg
72 pcs
United Kingdom
8421.99.90
72 pcs
Germany
8421.99.90
Description
Replacement Filter Element for Return-Line Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 114 Inner Diameter (mm): 68,2 Length (mm): 334 Sealing: NBR, β ratio >200Specification
| Style | Return Filter |
| Media | Glass Fiber |
| Efficiency 1 | 10µ @ β200 |
| Efficiency 2 | 12µ @ β1000 |
| Outer Diameter | 114.0 mm |
| Inner Diameter | 68.4 mm |
| Length | 333.0 mm |
| Bypass Pressure | 3.0 BAR bar |
| Δ Collapse Pressure | 20 bar |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
Stauff Product
Genuine Stauff RE-160-G-10-B/4
Inspected to ISO 9001:2015
