Summary

Donaldson P560525 Replacement Hydraulic Cartridge

Donaldson P560525
Donaldson P560525
Watch video
▶
Representative product image Product image feedback

Donaldson P560525 Hydraulic Cartridge

Brand: Donaldson
Description

Genuine Donaldson P560525 Hydraulic Cartridge offers superior filtration performance, effectively removing contaminants from hydraulic fluids. Its high-capacity design helps maintain fluid cleanliness and system efficiency.

Constructed from durable materials, this hydraulic cartridge is suitable for a wide range of industrial and heavy-duty hydraulic systems.

Price Match
$78.00
United States
8421.29.00
Shipping Terms

Description

Genuine Donaldson P560525 Hydraulic Cartridge offers superior filtration performance, effectively removing contaminants from hydraulic fluids. Its high-capacity design helps maintain fluid cleanliness and system efficiency.

Constructed from durable materials, this hydraulic cartridge is suitable for a wide range of industrial and heavy-duty hydraulic systems.

Specification

StyleHydraulic Cartridge
MediaSynthetic
Efficiency 18µ @ β1000
Outer Diameter 111.5 mm
Inner Diameter 62.2 mm
Length 127.0 mm
Donaldson Brand Logo

Donaldson Product

Genuine Donaldson P560525

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
8µ @ β1000
Efficiency 2
Style Hydraulic Cartridge
Outer Diameter 111.5 mm
Inner Diameter 62.2 mm
Length 127.0 mm
Media Type Synthetic
Flow Direction
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure
Seal
Temperature Range
