MicroFit MFHR50094 Replaces the SF Filter HY12117

HY12117
HY12117
Representative product image Product image feedback

MicroFit® UltraGen III MFHR50094 Return Filter | Replaces the SF Filter HY12117

Brand: MicroFit
Description

The MICROFIT® UltraGen III MFHR50094 is the MICROFIT® approved replacement to the SF Filter HY12117. Engineered and manufactured in Great Britain the MFHR50094

Price Match
$94.00
3.0 kg
0.0043 m³
120 pcs
United Kingdom
8421.99.90
1.29 kg
0.0065 m³
120 pcs
Italy
8421.29.80.90
1.37 kg
0.0043 m³
120 pcs
Italy
8421.99.90
Shipping Terms

Description

The MICROFIT® UltraGen III MFHR50094 is the MICROFIT® approved replacement to the SF Filter HY12117. Engineered and manufactured in Great Britain the MFHR50094

Specification

StyleReturn Filter
MediaWire Mesh
Efficiency 160µ
Outer Diameter 130.0 mm
Inner Diameter 64.5 mm
Length 250.0 mm
Bypass Pressure 1.7 BAR bar
Δ Collapse Pressure 10 bar
Seal MaterialNitrile
Temperature Range -30 - +100°C
Default Brand Logo

Same Fit-Form & Function

As the Genuine SF Filter HY12117

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
60µ
Efficiency 2
Style Return Filter
Outer Diameter 130.0 mm
Inner Diameter 64.5 mm
Length 250.0 mm
Media Type Wire Mesh
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

1.7 BAR
Collapse Pressure 10 BAR
Seal Nitrile
Temperature Range -30 - +100°C
